Colasit industrial, laboratory and building fans for chemically aggressive exhaust air and gases

Excellent service life and efficiency

Comprehensive product range

For flow rates of up to 132000 m³/h and a static pressure of up to 7000 Pa, also available as an ATEX version

Plastic radial fans / Plastic centrifugal fans



Colasit Plastic radial fans / Plastic centrifugal fans convey chemically aggressive exhaust air and gases and are characterized by the highest corrosion resistance. Depending on the requirements, the fans are made of thermoplastics PP, PPs, PPs white, PPs-el, PVDF, PVC or PE. For applications in potentially explosive atmospheres, the fans are available in ATEX version for zone 1 (category 2) or zone 2 (category 3).

CMVpro®

Volume flow
150 – 13500 m3/h
Static pressure
50 – 2800 Pa
Ex protection
EX Logo
Efficiency (tot. mech.)
83 %

CMVeco

Volume flow
150 – 13500 m3/h
Static pressure
50 – 3000 Pa
Ex protection
EX Logo
Efficiency (tot. mech.)
79 %

CMV

Volume flow
2900 – 127000 m3/h
Static pressure
200 – 1900 Pa
Ex protection
EX Logo
Efficiency (tot. mech.)
68 %

CMMV

Volume flow
2900 – 132000 m3/h
Static pressure
200 – 4000 Pa
Ex protection
EX Logo
Efficiency (tot. mech.)
70 %

CHVN

Volume flow
1500 – 132000 m3/h
Static pressure
400 – 5300 Pa
Ex protection
EX Logo
Efficiency (tot. mech.)
74 %

CHVS

Volume flow
60 – 5300 m3/h
Static pressure
450 – 7000 Pa
Ex protection
EX Logo
Efficiency (tot. mech.)
82 %

CCV

Volume flow
50 – 400 m3/h
Static pressure
50 – 900 Pa
Ex protection
EX Logo
Efficiency (tot. mech.)
44 %

CKV

Volume flow
50 – 350 m3/h
Static pressure
35 – 450 Pa
Ex protection
No
Efficiency (tot. mech.)
42 %

Radial fans are used wherever higher-pressure increases is required for the same exhaust air flow rate compared to axial fans. Colasit radial plastic fans are characterised by their long service life and energy efficiency. For standard fans, we offer short delivery times from stock worldwide.

Contact

Do you have any further requests or inquiries?
Contact us for a consultation.
Dinh Ma
Jérôme Bourquin
Alain Kaiser
Renzo Bonetti

Product selection

Quick selection of Colasit fans

More information

Best in class CMVpro®

In energy efficiency worldwide

Colasit is a leader when it comes to the product range, service life and energy efficiency for industrial fans made of plastic.

More information

ColaVent®

Professional online configurator for Colasit fans.

Individual configuration for your application.

More information

Exciting stories and solutions for plastic fans

Plastic fans for swimming pools - Colasit
28.01.2022Plastic fans

Colasit plastic fans for swimming pools and steam bath dehumidification

Frequently asked questions

In industry, terms such as industrial blower, industrial fan, radial blower, plastic ventilator, ATEX fan, ATEX duct fan, ATEX blower, centrifugal air blower, centrifugal fan, chemical extraction fan, chemical resistant fan, ec centrifugal fam, extractor fan, extractor ventilation fan, air exhaust fan, impeller centrifugal fan, industrial extraction fan, scrubber fan, small centrifugal fan, system air extraction fan, industrial fan, industrial blower, fan construction for gases are used.
